Technical Data Sheet-Closed Panel Alloy Specification

ALLOY SPECIFICATIONS
Top & Bottom Coil	AA 3105	H16, H24
Honeycomb Core	AA 3003	H16

PANEL PROPERTIES
Panel Thickness	6mm to 200mm	± 0.5mm
Top Coil Thickness	1.0mm, 0.7mm	± 0.05mm
Bottom Coil Thickness	0.7mm, 0.5mm	± 0.05mm
Panel Width (Max)	1500mm	± 2mm
Panel Length (Max)	< 9000mm	± 2mm
Weight (12mm)	4.0 kg/m²	± 0.2kg
Weight (25mm)	4.5 kg/m²	± 0.2kg
U Value	5.58W/m²K

HONEYCOMB CORE PROPERTIES
Honeycomb Cell Size (D)	10mm to 20mm
Honeycomb Foil Thickness	0.076mm

GLUE
Two Component PU - Automatically Sprayed

Cutomised Specifications are also available on request
